Summary

A 5MWh liquid-cooled battery container combines battery storage with cooling, battery management and protective systems. Buyers should confirm where the container supply ends and responsibility for AC conversion, site controls and installation begins.


What is inside the container?

A battery energy storage system (BESS) container typically houses battery modules and racks, a battery management system (BMS), liquid-cooling equipment, internal DC connections and protective systems. The MWh rating describes energy capacity; it does not define the complete equipment list.


For a concrete example, the TLS 5MWh reference configuration, model ESS-ES5016C-LP71173207, has approximately 5.016MWh nominal energy and a 2.5MW charge/discharge rating at 0.5P. Its baseline includes liquid cooling, a three-level BMS, integrated fire detection and suppression, a water interface, and an IP55 20ft enclosure. These are reference-configuration details; the project specification and agreed supply scope govern the delivered equipment.


Battery modules and DC equipment

Cells are assembled into modules and racks to achieve the required energy and DC voltage. Internal connections carry power from the battery assemblies toward the external conversion equipment. Isolation, protection and monitoring must work together so faults can be detected and affected equipment disconnected as designed.


Ask for a single-line diagram and an equipment list showing the battery terminals, protection devices and supply boundary. A description such as “battery container included” does not establish who supplies the external DC cables or their terminations.


Liquid cooling and battery management

Liquid cooling transfers heat from the battery assemblies through a coolant circuit. The reference configuration includes a chiller rated at 60kW of cooling capacity. That figure describes heat-removal capacity, not the electrical power the chiller consumes. Auxiliary electricity demand requires separate confirmation under defined operating conditions.


The BMS monitors battery conditions and communicates operating limits. A three-level arrangement coordinates measurements and control across successive battery assembly levels. It helps determine when charging or discharging must be limited or stopped. Site scheduling is a separate control function, normally handled by an energy management system (EMS).


Protective systems and the enclosure

The reference configuration includes fire detection and suppression provisions plus a water interface. The final fire-system design, external connections and site response arrangements require project-specific review. A component list alone does not demonstrate regulatory acceptance or complete site fire protection.


The enclosure provides mechanical and environmental protection. IP55 is an ingress-protection classification; it does not establish flood resistance or suitability for every installation environment. Installation requirements must be checked against the actual site.


Does the container include the PCS and transformer?

The power conversion system (PCS) converts between battery DC power and AC power. A transformer, switchgear, plant controls and site cabling may also be needed. Their inclusion and physical location depend on the contracted delivery level. TLS describes several integration levels on its BESS container page.


Before ordering, confirm:

  • Which batteries, auxiliaries and protective systems are factory installed.
  • Whether the PCS, transformer, switchgear and EMS are included.
  • Who supplies external cables, communications and auxiliary power.
  • Who performs installation, integration testing and commissioning.

A clear scope boundary makes quotations comparable and reduces missing work at site.


FAQ

Is 5MWh the energy delivered to the grid?

Not automatically. Nominal battery energy and usable AC energy are different quantities. The operating window, losses, auxiliary consumption and measurement point affect delivered energy.


Does liquid cooling guarantee a particular efficiency?

No. Cooling is one part of the system. Any efficiency claim needs a defined test cycle, temperature, power level and measurement boundary.


Is a water interface a complete site fire-protection system?

No. Its purpose, connection requirements and relationship to the wider fire strategy must be confirmed for the project.


Further Reading


Discuss Your BESS Supply Scope

For a relevant TLS quotation, send the required MW and MWh, installation location, intended application and requested equipment scope to sales@tls-containers.com. Identify any PCS, transformer or site controls already selected so the interfaces can be reviewed.


Short Summary

Before ordering an offshore workshop container, define the work activities, location, transport conditions, equipment loads, utilities, and safety interfaces. Agree the certification scope and acceptance tests before fabrication. A dimensioned floor plan is useful, but it does not establish whether the workshop can be lifted, connected, and operated as intended.


Start with the work the container must support

A mechanical repair workshop, an electrical maintenance room, and a welding workshop have different requirements. List the actual tasks, the largest workpiece, the number of users, and the equipment that will run simultaneously. Describe whether the unit will store tools only or support occupied work during normal operations.


Specify benches, vices, tool cabinets, machinery, handling aids, and consumables early. Record equipment mass and support footprints. A heavy machine can create local floor loads that are not adequately described by a single overall payload figure.


Separate the operating configuration from the transport configuration. Drawers, tools, cylinders, and workpieces may need different securing arrangements when the workshop moves. State which items remain onboard during lifting and which are removed.


Separate lifting certification from operational acceptance

The container’s transport structure and the equipment installed inside it need clearly defined assessment scopes. DNV-ST-E271 addresses offshore containers and lifting sets. DNV-ST-E272 addresses equipment assemblies, including design, layout, safety systems, installation, and operation. Applicability depends on the assembly and project requirements; do not assume either label covers everything. DNV E271 overview, DNV E272 overview.


Agree the required standard editions, certifying body, offshore operator review, and document deliverables. Ask the supplier to identify the boundaries of each certificate, including any customer-supplied equipment excluded from its scope.


Define the location and safety interfaces

Provide the offshore installation’s area-classification information and environmental design conditions. If hazardous-area suitability is required, identify the applicable classification, substances, temperature limitations, and protection approach with the responsible project specialists.


Explosion-protected lights alone do not establish that the complete workshop is suitable for a hazardous area. Tools, equipment, ventilation, possible ignition sources, and operating procedures also matter. Any proposed pressurization system needs an agreed control philosophy and response to loss of protection.


Define emergency escape, door clearances, fire and gas interfaces, emergency shutdown, and the connection to the installation’s alarm system where required. Specify fire-resistance requirements only against the applicable project basis; “offshore workshop” does not imply a universal fire rating.


Design ventilation around the process

Comfort cooling and contaminant control are different duties. Air conditioning sized for people and equipment heat does not establish control of welding fume, grinding dust, or solvent vapour.


For welding, define the process, materials, frequency, and workpiece size before selecting extraction. HSE guidance identifies capture at source as the most effective way to reduce welding-fume spread and describes local exhaust ventilation options. Use that guidance as a technical reference alongside the rules applicable to the project location. HSE welding controls.


Agree where replacement air enters and where extracted air discharges. Check the relationship with nearby air intakes, occupied areas, and any pressure-control system. The workshop needs a coordinated ventilation design, not independently selected fans and cooling equipment.


Confirm utilities and maintenance access

For electrical supply, provide voltage, frequency, phases, available capacity, earthing arrangement, and connection details. List starting loads and simultaneous demand. Define the responsibility for protection coordination and the interface between incoming supply and internal distribution.


For compressed air, water, drainage, or gases, identify service conditions and connection locations. Agree how waste fluids and consumables will be contained and removed. A drain connection should not be assumed to permit direct discharge.


Review the arrangement with doors and cabinet drawers open. Confirm room to use the machinery, reach isolation points, remove filters, and replace the largest serviceable component. Show external clearance requirements on the layout so that a workable factory arrangement remains usable on the installation.


Procurement inputs and acceptance tests

Issue a quotation package containing:

  • A task description, staffing assumption, and equipment schedule with masses and dimensions.
  • Transport gross mass limits, lifting requirements, and the operating location.
  • Environmental conditions, area classification, and required safety interfaces.
  • Utility data, connection responsibilities, and allowable external footprint.
  • Certification scope, drawing approval stages, and the delivery document list.
  • An acceptance plan with measurable criteria and named witnessing responsibilities.

Select tests to match the supplied functions. These may include electrical checks, ventilation measurements, alarms and interlocks, equipment operation, and verification of markings and documents. Separate factory verification from tests that require final site connections. Define how outstanding items will be closed before operational acceptance.


FAQ

Is a standard 20-foot size enough to start manufacturing?

No. External dimensions do not define usable space, equipment loads, escape routes, ventilation, or connection positions. Freeze the functional layout and major interfaces first.


Can customer-supplied tools be added after certification?

Only after checking their effect on the approved configuration. Added equipment can change mass, centre of gravity, electrical demand, ventilation, and hazardous-area suitability. Agree a change-review process.


Does a certified offshore container automatically qualify as a welding workshop?

No. Structural lifting approval does not demonstrate that welding-fume control, ignition risks, utilities, and operational interfaces have been addressed.


Prepare your workshop enquiry

Send TLS Offshore Containers your intended tasks, equipment list, installation requirements, and utility data. Ask for a coordinated layout and a proposal identifying structural certification, operational safety scope, interface responsibilities, and acceptance tests.


Further Reading


Short Summary

An ISO shipping container is not automatically suitable for offshore lifting. Freight transport approval does not establish that the container, its lifting points, and its lifting set can withstand the offshore handling conditions specified for a project. Buyers need evidence covering the complete lifting arrangement and the unit’s current condition.


What freight container approval actually tells you

An ISO freight container is designed around defined transport, handling, and stacking requirements. The International Convention for Safe Containers, or CSC, provides safety requirements and approval arrangements for containers used in international surface transport.


A CSC plate is relevant evidence for that purpose; it is not a blanket approval for every crane operation. IMO explains the purpose of CSC here.


The procurement question is therefore specific: does the supplied evidence cover the intended offshore transfer, at the proposed gross mass, using the proposed lifting set?


Why offshore handling changes the design problem

During transfer between a vessel and an offshore installation, relative motion can change the loads acting on the suspended unit. Contact with a moving deck or nearby structure also creates a different problem from routine terminal handling. Offshore suitability must address the intended dynamic lifting and impact conditions, rather than relying on a static weight comparison.


For example, IMO’s published IMDG amendments explicitly distinguish offshore containers handled in open seas from CSC containers and identify dynamic lifting and impact forces as design considerations. The project must establish its applicable current requirements with the approving authority and offshore operator. See IMO Resolution MSC.406(96), section 7.3.2.3.


Assess the complete lifting arrangement

Adding padeyes does not demonstrate offshore suitability. Loads must travel from the lifting set through the lifting points and supporting structure into the loaded container. The assessment needs to cover that full load path, including connections and the consequences of the actual payload distribution.


A practical review should establish:

  • The approved gross mass, tare mass, available payload, and permitted loading arrangement.
  • The lifting-point geometry and the compatible sling and shackle arrangement.
  • The design basis for structural materials, welds, fabrication checks, and required testing.
  • The effect of doors, openings, equipment supports, and later modifications on the structure.
  • How internal equipment and loose cargo are restrained during transport and lifting.

These are procurement review inputs, not a substitute for calculations or certification. A successful proof load alone does not establish all aspects of suitability, such as material traceability or the condition of hidden connections.


What should the certification evidence cover

DNV-ST-E271, commonly called DNV 2.7-1, provides requirements for offshore containers and lifting sets, including manufacturing, testing, marking, and periodic inspection. Specify the applicable standard and edition in the purchase order, together with the required certification scope. DNV’s standard overview describes that scope.


Ask for evidence tied to the actual supplied unit. A brochure statement or a certificate for another design is insufficient to establish the status of the delivered container. Check identification numbers, approved drawings, operating limitations, lifting-set records, and inspection status against the physical equipment.


Certification also does not authorize a particular lift by itself. The offshore operator still needs to accept the unit and plan the operation around crane capability, vessel conditions, weather limits, deck space, and personnel controls.


Procurement inputs to define before requesting a quotation

Give the supplier the intended transfer route and offshore location, the operator’s acceptance requirements, the required certification basis, and the lowest design temperature. Provide the payload inventory, individual equipment masses, likely centre of gravity, overall size limits, and any equipment that will remain inside during lifting.


Also define who supplies the lifting set, which documents must accompany delivery, and who handles inspection after entry into service. Identify every proposed opening or fitted item before design approval. A late door cut-out or heavy equipment addition may require reassessment of the approved configuration.


For an existing unit, provide its drawings, certificates, inspection history, repair records, and photographs of damage or corrosion. Ask the certifying body to assess the conversion route before treating reuse as a cost saving.


FAQ

Can an ISO shipping container ever be used offshore?

Potentially, but its ISO freight-container status alone is insufficient. Suitability depends on the intended use, verified design, condition, lifting arrangement, and acceptance requirements. Offshore storage and repeated open-sea lifting are different service conditions.


Does a higher payload rating make it suitable for offshore lifting?

No. A payload figure does not describe the complete design load cases, lifting geometry, impact resistance, or inspection status. Compare approved service conditions as well as mass limits.


Are corner castings automatically acceptable offshore lifting points?

No. Use only the lifting method covered by the unit’s approved design and handling instructions. Do not infer approval from the presence of corner castings or attach an improvised sling arrangement.


Discuss your offshore lifting requirement

Send TLS Offshore Containers your payload list, intended offshore transfer conditions, dimensional limits, and operator specification. Request a proposal that identifies the container design basis, lifting-set scope, certification deliverables, and items requiring operator approval before manufacture.
