Offshore shipping containers are widely used for the transportation and hoisting of goods or equipment between offshore facilities and ships in harsh environments with high temperature, high humidity, and high salt spray. Therefore, there are extremely high requirements for the anti-corrosion of the surface of the offshore container.
The coating process steps of TLS are as follows:
1. Preprocessing
Remove the oxide scale, rust, grease, dirt, and other attachments on the surface of the exposed steel structure to ensure the anti-corrosion performance of the coating; zinc-rich primers are applied automatically on the assembly line after the steel is shot-blasted. It temporarily protects the surface of freshly shot steel, preventing it from rusting in the gaps made during the container's manufacture.
2. Shot-blasted the whole container
Before painting, the surface of the weld and the heat sensitive area of the weld should be shot-blasted. The surface of the steel structure should be free of burrs, bumps, dust, dirt, no painting, sharp edges, and all rough-cut edges should be ground to a radius of at least 2mm;
3. Pre-coating
Pre-coating is applied to areas that are not easy to coat, including, but not limited to, the edges of steel plates, welds, corners, bolt holes, beam edges, and other areas that are difficult to paint.
4. Spray
Each coat should be applied evenly over the entire surface, and defects such as missing paint, sags, and drips must be avoided. And each coating should contain no pinholes, blisters, and leaks.
5. Drying: Speed up the curing process.
TLS uses environmentally friendly water-soluble paints, and the coating operators have relevant technical certifications. TLS containers are not prone to corrosion, paint failure, fading and discoloration which can make the container work better for its use value.
The coating process steps of TLS are as follows:
1. Preprocessing
Remove the oxide scale, rust, grease, dirt, and other attachments on the surface of the exposed steel structure to ensure the anti-corrosion performance of the coating; zinc-rich primers are applied automatically on the assembly line after the steel is shot-blasted. It temporarily protects the surface of freshly shot steel, preventing it from rusting in the gaps made during the container's manufacture.
2. Shot-blasted the whole container
Before painting, the surface of the weld and the heat sensitive area of the weld should be shot-blasted. The surface of the steel structure should be free of burrs, bumps, dust, dirt, no painting, sharp edges, and all rough-cut edges should be ground to a radius of at least 2mm;
3. Pre-coating
Pre-coating is applied to areas that are not easy to coat, including, but not limited to, the edges of steel plates, welds, corners, bolt holes, beam edges, and other areas that are difficult to paint.
4. Spray
Each coat should be applied evenly over the entire surface, and defects such as missing paint, sags, and drips must be avoided. And each coating should contain no pinholes, blisters, and leaks.
5. Drying: Speed up the curing process.
TLS uses environmentally friendly water-soluble paints, and the coating operators have relevant technical certifications. TLS containers are not prone to corrosion, paint failure, fading and discoloration which can make the container work better for its use value.
THE PROCESS OF CONTAINER MANUFACTURING
Step 1: a. preprocessing of sheet and section steel b. cutting and processing of section steel c. stamping
Step 2: a. welding prefabricationb. bottom frame fabrication c. end frame fabricationd. top side fabrication
Step 3: Welding assembly
Step 4: Sand paint (primer and paint)
Step 5: Internal installation of the structure (internal wall, ground), external installation (door, window)
Step 6: Decals and logos
Step 7: Performance test
Step 8: Interior decor
Step 1: a. preprocessing of sheet and section steel b. cutting and processing of section steel c. stamping
Step 2: a. welding prefabricationb. bottom frame fabrication c. end frame fabricationd. top side fabrication
Step 3: Welding assembly
Step 4: Sand paint (primer and paint)
Step 5: Internal installation of the structure (internal wall, ground), external installation (door, window)
Step 6: Decals and logos
Step 7: Performance test
Step 8: Interior decor
The customized ultra-wide laboratory container is being assembled, we will follow up every process in real time, and we will take every detail seriously.
Rest assured, products tailored to your needs are sure to satisfy you.
